- Distortion Circuitry: Glass Diode, Back-to-Back Stack
- Bypass: True Bypass
- Gain Control Range: 8dB to 16dB
-
EQ Center Frequencies:
- Bass: 90Hz � 11dB
- Mid: 750Hz � 11dB
- Treble: 2.1kHz � 12dB
-
Gain Limits:
- Minimum Gain: 20 - 20kHz, 112dBv
- Minimum Gain: 400 - 20kHz, 114dBv
- Maximum Gain: 20 - 20kHz, 97.5dBv
- Maximum Gain: 400 - 20kHz, 98dBv
- THD @10MVRMS Input @1kHz w/ 12dB of Gain: 0.15%
- Max Output Before Saturation: .6VRMS
- Saturation Input Impedance: 470 k?
- Output Impedance: 1 k?
- Power: 9V Battery or External 9V - 18V DC Adapter
